UPVC Electromagnetic Flow Meters MS FL 0117


MS Controller Based TDS Indicators / controller


request


Feature:

• Full Bore Type
• Simple & cost effective construction
• Provides wide flow ranges
• Outstanding accuracy
• Operates over wide ranges of temperature & pressure
• Easy maintenance as no moving parts
• Pulsed DC coil excitation
• Integral grounding
• Remote Electronics

DESCRIPTION:

MICROSET series MS FL 0117 are micro-controller based full-bore type electromagnetic Flow Meters specially used for various industrial applications. These Flow Meters accurately measure the flow rate of conductive liquids & slurries in closed pipes. Due to its simple & rigid design, the Flow Meters is an obstruction-less & maintenance-free instrument in place of conventional mechanical flow measuring devices. The use of 'Pulsed DC' technology offers highest ability & better measuring accuracy in the form of electrical signal 4-20 mA DC linearly proportional to volumetric flow. The instrument is based on Faraday's law of electromagnetic induction.

The instrument in the flow tube generates a magnetic field. The fluid flowing through this magnetic field generates a voltage that is proportional to the flow velocity. Corresponding electrical output is provided with respect to measuring flow range.



Advantages and Disadvantages:

• A magnetic Flow Meters provides an unobstructed flow path, with negligible pressure drop due to its pipe

• The typical accuracy for a magnetic Flow Meters is + 0.5 % of full scale. This is among the best of the various pipe Flow Meters.
• The effect of fluid viscosity on flow through a magnetic Flow Meters is essentially the same as for flow through the pipe itself.
• The magnetic Flow Meters can be used for pipe flow measurement of either clean or dirty liquids, including wastewater, corrosive liquids, or slurries.

Disadvantages of Meter:

• The magnetic Flow Meters is used primarily for liquids. It doesn't work well for measurement of gas, solvents, alcohol etc. flow rate.
• In order to use a magnetic Flow Meters for measurement of a liquid's flow rate, liquid must be conductive.

Applications:

Electromagnetic Flow Meters can be used for precise flow measurement of all electrically conductive liquids such as slurries, sewage, milk, water and wastewater.

Electromagnetic Flow Meters has many applications across many industries

• Chemical measurement, Water/waste water Treatment
• Effluent Treatment
• Building Automation & plant automation
• Pulp, paper, Food & Beverage
• Advanced Metering Infrastructure
• Meter Data Management
• Automated meter reading
• Drinking water
• Flow measurement
• Public utility
• Utility sub meter
• Water conservation



upvc-electromagnetic-flow-meter-ms-fl-01171

Principle of Operation:

E: Induced Voltage
B: Magnetic Field Strength
D: Inner Diameter of Pipe
V: Average Velocity
C: Constant E BDV/C



Specification:

Media Liquids
Viscosity 200 cp max
Conductivity Minimum 10 μS/cm
Line Size 15- 100 mm NB
Excitation Pulsed DC coil
Type of Output 4-20 mA DC Isolated
Calibration Range As per requirement (Factory Calibrated)
Accuracy ±0.5% FS
Linearity ±0.5%
Repeatability ±1%
Process Temperature 60°C max
Process Pressure 06 kg/cm2
Material of Construction of Sensor Hastelloy C / SS 316L
Body UPVC/HDPE
Wetted Parts UPVC/HDPE
Power Supply 24VDC-230 VAC, 50Hz ±10%
Power Consumption <10 VA
Response Time <100 micro
Temperature Coefficient ±0.01% /°C
Transmitter Enclosure IP 65
Process Connections Union Coupling, Flange, Threaded BSP
Operating Conditions Temp 0-55°C / Humidity 5-95% non-condensing

FLOW RATE OF VELOCITY:

METER SIZE
FLOW RATE (m3/Hr) AT DIFFERENT VELOCITY
INCH DN (mm) 0.3m/s 1.00m/s 12.00m/s
1/2" 15 0.1909 0.636 7.634
1" 25 0.5301 1.767 21.20
1 1/2" 40 1.358 4.524 54.28
2" 50 2.121 7.068 84.83
2 le 65 3.584 11.95 143.2
3" 80 5.429 18.90 217.1
4" 100 8.483 28.2 339.2
5" 125 13.26 44.18 530.1
6" 150 19.09 63.62 763.1
8" 200 33.93 113.1 1357
10" 250 53.02 176.7 2120
12" 300 76.35 254.5 3053
14" 350 103.9 364.4 4156
16" 400 135.8 452.4 5428
